Overview

---

CyberPower Value800E offers home and office users a reliable battery backup and safeguards office PCs, network communication equipment, and other electronic devices from surges, spikes, brownouts and other power incidents. Designed with GreenPower UPS™ Technology to improve operating efficiency and to minimize energy consumption, users can enjoy significant energy cost savings over conventional UPS systems.

FEATURES

• - Line-interactive UPS Topology
• - Energy Saving Technology
• - Simulated Sine Wave Output
• - Automatic Voltage Regulation (AVR)
• - Surge and Spike Protection
• - Phone/Fax/Modem/DSL/Network Protection
• - PowerPanel® Management Software
• - Tower Form Factor

Specification

---

GENERAL

Phase	Single Phase
UPS Topology	Line-interactive
Energy Saving Technology	GreenPower UPS™ Bypass Technology

INPUT

Nominal Input Voltage ( Vac )	230 ± 10%
Input Voltage Range ( Vac )	165 ~ 280
Input Frequency ( Hz )	50 ± 5 60 ± 5
Input Frequency Detection	Auto-sensing
Rated Input Current ( A )	3.64
Input Connector Type	IEC C14
Detachable Power Cord Plug Type	NEMA 5-15P
Power Cord Length (ft.)	6
Power Cord Length (m.)	1.8

OUTPUT

Capacity (VA)	800
Capacity (Watts)	480
On Battery Waveform	Simulated Sine Wave
On Battery Voltage(s) ( Vac )	230 ± 10%
On Battery Frequency ( Hz )	50 ± 1% 60 ± 1%
Automatic Voltage Regulation (AVR)	Single Boost, Single Buck
Overload Protection	Fuse
Outlet(s) - Total	3
Outlet Type	AS x 3
Outlet(s) - Battery & Surge Protected	3
Typical Transfer Time ( ms )	4

BATTERY

Runtime at Half Load ( min )	7
Runtime at Full Load ( min )	1
Typical Recharge Time ( Hours )	8
Start On Battery	Yes
User-replaceable	No
Battery Type	Sealed Lead-acid

SURGE PROTECTION & FILTERING

Surge Suppression ( Joules )	125
EMI/RFI Filtration	Yes
Phone/Network Protection RJ11/RJ45 (Combo)	1-in, 1-out

MANAGEMENT & COMMUNICATIONS

LED Indicators	Power On , Line Mode , Battery Mode , Low Battery
HID Compliant USB Port(s)	1
Serial Port	RS232
Audible Alarms	Battery Mode , Low Battery , Overload , UPS Fault
Management Cable ( pcs )	Power Cord x1 , USB Cable x1
Power Management Software	PowerPanel® Personal

PHYSICAL

Form Factor	Tower
Enclosure Construction	Plastic
Color	Black

PHYSICAL SIZE - UPS MODULE

Dimensions (WxHxD) (in.)	3.937 x 5.512 x 11.811
Dimensions (WxHxD) (mm.)	100 x 140 x 300
Weight (lbs.)	11.46
Weight (kg.)	5.2

ENVIRONMENTAL

Operating Temperature (°F)	32 ~ 104
Operating Temperature (°C)	0 ~ 40
Operating Relative Humidity (Non-condensing) ( % )	0 ~ 90
Operating Elevation ( feet/meters )	0-10,000 feet (0-3,000 meters)
Storage Temperature (°F)	-4 ~ 122
Storage Temperature (°C)	-20 ~ 50
Storage Relative Humidity (Non-condensing) ( % )	0 ~ 90
Storage Elevation ( feet/meters )	0-10,000 feet (0-3,000 meters)
Online Thermal Dissipation ( BTU/hr )	102
Audible Noise at 1.5M from Surface of Unit ( dBA )	40

CERTIFICATIONS

Certifications	CE
RoHS	Yes

WARRANTY

Product Warranty Period (Year)	3
Battery Warranty Period (Year)	2

Dowloads

---

Datasheet

	File Name : Value600E/ Value800E/ Value1000E/ Value1200ELCD/ Value1500ELCD/ Value2200ELCD (AS) Language : English Version : v2	Download
